SPECIFICATIONS
| WATTS | L | D | H | d ± 0.05mm |
| 1/4W | 6.8±0.5 | 2.4±0.3 | 26.0±2.0 | 0.5 |
| 1/2WS | ||||
| 1/2W | 9.8±0.5 | 3.5±0.3 | 25.0±2.0 | 0.55 |
| 1WS | ||||
| 1W | 11.5±1.0 | 4.5±0.5 | 34.5±3.0 | 0.65 |
| 2WS | ||||
| 2W | 15.5±1.0 | 5.0±0.5 | 33.0±3.0 | 0.75 |
| 3WS | ||||
| 3W | 17.5±1.0 | 6.2±0.5 | 32.0±3.0 | 0.75 |
| 5WS | ||||
| 5W | 24.5±1.0 | 8.0±1.0 | 28.0±3.0 | 0.75 |
RATED POWER
| Rated power | Resistance range(Ω) |
Resistance tolerance | Max-working voltage | Max-overload voltage | Withstanding voltage (V) |
| 1/4W / 1/2WS | 10K~1000M |
±1%(F) ±5%(J) |
1000V | 1500V | 500 |
| 1/2W / 1WS | 1500V | 2000V | 600 | ||
| 1W / 2WS | 2000V | 3000V | 750 |
||
| 2W / 3WS | 3000V | 4000V | |||
| 3W / 5WS | 4000V | 5000V | |||
| 5W / 7WS | 5000V | 7000V |
